Disassembly

1. Loosen cable screw (20) and disconnect floodlight from the
control box.
2. Loosen air regulator (21/1) by turning it anti-clockwise.
3. Unlock and remove pneumatic button (38/1; 38/2) by turning
it anti-clockwise.
4. Loosen screws (49).
5. Loosen screws (95.1).
6. Remove cover (93).
7. Loosen screws (95) and remove nozzle housing (102.1).
8. Loosen screws (52), support ring (28) and support ring seal
(27).
