PR2000, PR2500
3. At the marked points, drill holes with a diameter of 3 mm from the outside into
the external wall (fig. 5, page 5).
4. Put the upper and lower sections of the mounting bracket together.
5. Clean the outer sides of the lower section and the installation surface in the
vehicle.
I
NOTE
Make sure that no glue gets on to the movable upper section of the
mounting bracket.
6. To glue and seal, apply an elastic adhesive, such as Sikaflex
to the back of the mounting bracket.
7. Fasten the mounting bracket with drill screws or rivet the mounting bracket in
place (fig. 5, page 5).
Installing the crank bracket
➤ Install the mounting bracket for the crank at a suitable location inside the vehicle
(fig. 6, page 6).
Adjusting the awning arm's inclination angle (PR2000 only)
A
NOTICE!
Changing the inclination angle effects the closing of the awning. Make
sure the awning is still working properly. If necessary, readjust the
inclination angle.
➤ Proceed as shown (fig. 7, page 7).
EN
Installing the awning
®
-221 for example,
17
