TAKATA I-SIZE BASE (PLUS), and remove it from
your vehicle.
Removing the TAKATA I-SIZE BASE (PLUS)
Step 1 – Unlock the ISOFIX connectors
[MIDI_I-SIZE_PLUS_030] Separate the connectors
on the TAKATA I-SIZE BASE (PLUS) from the
ISOFIX points in the vehicle, by moving the locking
sliders of the release sliders down and, at the same
time, pulling the release slider on each connector
forward (in the direction of travel). The components
have been separated if a red marking can be seen on
the top of each ISOFIX connector.
Step 2 – Retract the ISOFIX connectors
[MIDI_I-SIZE_PLUS_028] Press the left-hand button
on the ISOFIX length adjuster as far in as possible.
The button is positioned on the inner side of the
TAKATA I-SIZE BASE (PLUS). At the same time,
push the left-hand connector back into the TAKATA
I-SIZE BASE (PLUS).
The two ISOFIX connectors must be adjusted
independently. Repeat Step 2 for the right-hand
connector.
NOTE!
The connectors have been fully retracted when all
fi gures from 1 to 5 are displayed on the top of the
ISOFIX connectors.
Step 3 – Fold in the support leg and remove it
[MIDI_I-SIZE_PLUS_025 + MIDI_I-SIZE_PLUS_026]
Fold the support leg in, as described in Section 3 – Basic
instructions (Adjusting the support leg). You should now
be able to remove the TAKATA I-SIZE BASE (PLUS)
from your vehicle.

5. SECURING YOUR CHILD

NOTE!
For safety reasons, children should always get in and
out from the passenger side of the vehicle, or directly
onto a sidewalk.
Step 1 – Adjust and fasten the inner padding and straps
[MIDI_I-SIZE_PLUS_021 + MIDI_I-SIZE_PLUS_022
a + b] Before sitting your child in the TAKATA MIDI
I-SIZE (PLUS), loosen and open the straps, as described
in Section 3 – Basic instructions (Loosening the straps
and opening the buckle), and move them out of the way.
26
[MIDI_I-SIZE_PLUS_006 + MIDI_I-SIZE_PLUS_007]
Once your child is sat in the TAKATA MIDI I-SIZE
(PLUS), place the shoulder straps over the shoulders and
the lap belt over your child's lap, taking care not to twist
or tangle the straps.
CAUTION!
Check that the inner padding and shoulder strap
connection are correctly positioned. The wings of the
inner padding with the AIRPADS protect the head,
and should therefore be positioned behind your child's
head, and above the shoulders. The shoulder strap con-
nections are correctly positioned for the:
[MIDI_I-SIZE_PLUS_049] TAKATA MIDI
I-SIZE (PLUS) in a backward-facing position if
they are a little below your child's shoulders. If
this is not the case, move the adjustable inner
padding up or down accordingly.
[MIDI_I-SIZE_PLUS_050] TAKATA MIDI
I-SIZE (PLUS) in a forward-facing position if
they are a little above your child's shoulders. If
this is not the case, move the adjustable inner
padding up or down accordingly.
Step 2 – Close the belt buckle
[MIDI_I-SIZE_PLUS_051 a + b] To secure the straps on
the TAKATA MIDI I-SIZE (PLUS) child car seat, bring
the two magnetic belt tongues together again.
Push the tongues fi rmly into the buckle, until you hear
them click into place.
WARNING!
Before every journey, always ensure that the tongues
and buckle are locked together. You can check this by
pulling the tongues up, without pressing the red button
on the buckle.
Step 3 – Adjust the lap belt
WARNING!
Pull the lap belt down as far as possible, so that the lap
area of your child is protected. If the lap belt runs
across your child's stomach, there is a risk of internal
injuries in the event of an accident.
Ensure that the cushion behind the buckle has not
slipped out of place, so that it no longer protects your
child against the buckle's plastic components.
Step 4 – Tighten the straps
[MIDI_I-SIZE_PLUS_052 a + b] To tighten the straps,
