Installation
4-2
Default UPS Shutdown Setting: During a loss of utility power, the
SNMPWEBCARD is configured to shut down the UPS system 2 minutes after a low
battery signal is received from the UPS. This allows the UPS to provide the
maximum available runtime to connected equipment. If you want to change the
default setting, follow these instructions:
1. From the initial PowerAlert Status page, click the Settings button
the screen, then click the Events button
2. From the Event Settings page, confirm that Low Battery
highlighted, then click the Settings... button
3. In the pop-up dialog window
Save Changes button
4-3
Attach Faceplate: Using one hand to hold the card in place, temporarily detach the
network cable. Align and attach the faceplate that matches your UPS system, using
screws from the accessory slot cover. Reattach the network cable.
Note for Network Management System Users Only: Two MIB files - Tripplite.mib and
RFC1628.mib - must be loaded on each Network Management Station that will
monitor the UPS system via SNMP. The files are provided on the CD-ROM included
in the product package.
, enter your preferred settings and then click the
F
.
G
B
that appears at the left side of the screen.
B
toward the bottom of the screen.
E
A
7
at the top of
A
and Shutdown
C D
C
D
E
F
G
are
