Instructions for use
7-Reading will be indicated by a continuous alarm, af-
ter the blinking alarm, that will last 3 seconds.
Do not move or remove the pen from the incu-
bation and reading position during this process.
Once the audible alarm is finished, the incubator will
print a ticket with the result and will inform the rea-
ding results by turning on one of the five PRO panel
lights on. Each light corresponds to the aproximate
protein range present in the sample. Remember the-
se values are achieved by through a BSA (Bovine Seric
Albumin) calibration curve.
If the sample is free of proteins and allergens, the
light will turn on.
To perform a new reading, press and hold the
button for 1 second and repeat steps 1 to 7.
Read the directions for use of each product and
be aware of the sensibility limits.
Cuantitative Results: For IC10/20FR-2.7 firmware
version or higher (others versions could report diffe-
rent values).
1 2 3 4 5
3 µg
Approximate amounts of
5 µg
BSA expressed in µg
10 µg
15 µg
>
<15 µg
Figure 1
1/A
1/B
Remove the swab
from the device.
For dry surfaces,
apply 3 drops of
moisturizer on the
swab or the surface,
and then swab the
surface.
IC10/20FR Page 10
1/C
1/D
1/E
Reading cone
1/F
1/G
Place the swab back
into the pen.
Press the swab
downwards firmly.
Lift the swab until it
disappears from the
reading cone.
Shake downwards
vigorously for 10
seconds. The solution
will turn green.
Press the swab
downwards again
completely.
