Commissioning
of the mounting plate must show upwards.
5. Align the mounting plate horizontally.
6. Mark two diagonally opposite bores using the mounting plate as a template
(see P in fig. 2).
7. For stone walls, drill the marked holes with a 5 mm masonry drill.
If wooden walls are present, the screws can be directly screwed into the
wood. Pre-drilling with a 1.5 mm wood drill facilitates the screw installation.
8. Insert the dowels into the bores.
9. Install the mounting plate with the supplied screws (see fig. 3 page 4).
10. Install the interchangeable frame onto the mounting plate.
11. Position the device onto the mounting plate and latch it into the clips.

5.2.3 Installation on flush-type box

The fixing holes in the mounting plate can be used for installation onto a flush-type box.
1. Remove the mounting plate from the room control unit Display S Floor Heating.
2. Align the mounting plate horizontally on the flush-type box.
3. Install the mounting plate with the correct screws (see Q in fig. 2).
4. Install the interchangeable frame onto the mounting plate.
5. Position the device onto the mounting plate and latch it into the clips.
44
