Technical Features - Thonet & Vander RÄTSEL BT Operación Manual

EN

TECHNICAL FEATURES

POWER OUTPUT: 72W RMS (32W + 20W x 2)
FREQUENCY RESPONSE: 30Hz - 20kHz
DISTORTION: <0.1% - 1W
S/N: >75dB
SEPARATION: >55dB
ACOUSTIC BOX MATERIAL: Wooden box HDAA
ACOUSTIC BOX SIZE: 253 x 253 x 365 mm
DRIVER SIZE: Woofer 6,5"
DRIVER MATERIAL: Cane Lignin
IMPEDANCE/POWER: 8 Ω 50W
SATELLITE SIZE: 253 x 100 x 111 mm
MID-RANGE SIZE: 3"
MID-RANGE MATERIAL: Cane Lignin
IMPEDANCE/POWER: 4 Ω 10W
TWEETER: 0,5"
TWEETER MATERIAL: Polyethylene micro sheets
IMPEDANCE/POWER: 4 Ω 5W
CONTROL BOX SIZE: 210x70x20¬0mm
ANTIMAGNETIC SHIELD
CONTROLS: Volume, treble, bass
REMOTE CONTROL: Wireless
INPUTS: Bluetooth v2.1 + EDR (Transmission distance 10M) /
NFC / 2 RCA stereo / 3.5mm stereo
OUTPUTS: 3.5mm stereo
ACCESORIES
_ Audio cable 2 RCA - 3.5mm stereo cable
_ 3 cable to connect the passive speakers
_ Power cable (IEC 60320 C7)
_ Power cable (IEC 60320 C7) UK plug BS 1363
*Included in certain countries.-
STAND-BY
The speaker will starts in stand-by mode. To turn it on press the
power button on the remote control or the volume/input knob. If
you want to put on stand-by hold down 3 seconds volume/input
knob or use the remote control.
18
POWER OF FREEDOM
