Cutter blades for automobile glazing
applications (figure 5).
Guide the straight, bent or offset cutter blades
at a right angle to the window flange; blade A
– D.
For U-shaped cutter blades, pay attention that
the traverse of the cutter blade is led parallel
to the window pane of the vehicle; blade E –
F.
A
E F
The scraper knife is used for cutting back
bond remainders on the window flange or the
pane. Before re-bonding the vehicle window,
cut back the remaining bead to a height of
approx. 2 mm; blade G.
Cutter blades marked with a symbol may only
be operated as indicated.
B C
G
en
D
Symbol on the cutting blade
17
Fig. 5
