Remove the duct knockouts using a lat blade
⁄
Installation
Determine installation height
The igure above shows a typical installation of the hood.
are available to ill the space between the hood and ceiling
NOTICE: The hood could incur some damage from heat
if a THERMADOR MASTERPIECE ® series cooktop is opera -
ted with multiple burners at high settings under a hood that
is installed at minimum clearances.
4 5 / "
16
(110)
11"
(280)
30" (762) min over a gas cooktop
30" (762) min over an electric cooktop
