Electrical Connection

WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
•
•
•
A
C
•
E
B
A
A. Home power supply cable
B. UL listed or CSA approved
strain relief
C. Black wires
•
B
A Juction Box
B Knockout
C Juction Box cover
C
D
F
D. UL listed wire connectors
E. White wires
F. Green (or bare) and yellow-green
ground wires
•
WARNING
Electrical Shock Hazard
Electrically ground blower.
Connect ground wire to green and yellow ground wire
in terminal box. Failure to do so can result in death or
electrical shock.
•
•
•
•
