RFX9600 Starter's Guide

Unpacking the Extender

Pronto Serial Extender
Front Panel
Back Panel
4 dipswitches for
the IR outputs
Power input
4 IR ports
3
Power LED
Ethernet LED
Busy LED
Extender ID
switch
5V DC output
Ethernet input (RJ45)
4 groups of 4 LEDs each for the
• IR ports;
• Serial (RS232) ports;
• Sensor inputs;
• Relay outputs.
Configuration
switch
Grounding
4 Power sense inputs
4 RS232 ports –
3 DB9 connectors and
one 3-pin connector
4 Relay outputs
