Thank you for choosing Vaporesso Products!
Please read this manual carefully to ensure
proper use. For additional information or
questions regarding to this product or its use,
please visit www.vaporesso.com
Main features
Drip tip
● Eco Universal Coil Inside
● Revolutionary Leak Free Design
Package Include
● Top Air Flow
● Easy Coil Replacement System
1 x VECO SOLO with ECO Universal Coil preinstalled
● Pass-Through
1 x Extra ECO Universal Coil
● Sleek and Modern Design
1 x USB Charger Cable
Specification
Battery: Lithium 1500mAh Built In
Casting:Zinc Alloy and stainless steel
Dimension: 22 x100mm
Thread: 510 thread
Weight: 82 +/-5 g
Capacity: 2 ML
Standby Current:﹤30uA
As a new member of the VECO family, VECO SOLO Kit by Vaporesso is sleeker in design while maintaining the smooth airflow.
It adopts the ECO Universal Coil (EUC) so that you only need to replace the coil head inside without changing the metal sleeve that is truly
ECO friendly. Combining the benefits of a Vapor Pen and an All-in-On, it has the tank built onto the base, so you could easily change the
coil and or clear the tank whenever needed in a compact design.
VECO SOLO, the one for you!
How to Use
1.Switch On/Off: Press the fire button 5 times in quick succession within 2 seconds to turn the device on. In the same way, the device will
be powered off after 5 presses.
2.Vaping:Hold the fire button and inhale through the mouthpiece. Release the fire button and exhale.
3. Filling E-liquid:This easy top-fill tank will only ask of you to screw out the lid and fill in the chamber when the base is securely shut.
Be sure to safely position the glass part when this process is in place to avoid spillage.
4. Changing Atomizer: Unscrew the tank from the base to remove and insert a new atomizer . Pull the EUC out from the base and insert a
new one. Screw the Base on. Wait after replacing to make sure the coil is well primed.
VECO SOLO Kit
Quick Guide
Lid
Pyrex glass tube
Micro USB
Power button
6.Charging:
Simply charge VECO SOLO Kit by connecting it with a computer or a wall adapter via USB cable. When it's fully charged, the button light
will go out.
The LED Indicator will be white if the battery is more than 70%,turn blue if the battery is more than 30% and turn red if the battery is less
than 30%.
Function:
Short Circuit Protection:
1.When the short circuit occurs before working, the button light flashes for 5 times and there will be no output power.
2.Low Wattage Protection
When the battery voltage is lower than 3V, the fire button light flashes for 3 times and the battery will be locked.
3.Over Vaping Protection
Adaptor
When the fire button is pressed for more than 10 seconds, the light flashes 3
times then goes off. The battery will be locked.
4.Low Battery Protection
When the battery is less than 10%, the light will flashes till it goes off completely.
Note:
1.Please power-off the VECO SOLO Kit when not in use.
2.Do not to press the button if the VECO SOLO Kit is not in use.
3.Only have your VECO SOLO Kit repaired by Vaporesso. Do NOT attempt to repair it on your own as it may lead to further damage to the
item and/or personal injury.
Caution
1.The device is intended for usage by people over 18, NOT by non-smokers, children, pregnant or breastfeeding women, people with or at
risk of heart disease, or people taking medication for depression or asthma. The electronic cigarette is not a smoking cessation device.
2.Please keep this unit out of reach of children or pets;
3.Please don' t drop, throw or abuse your device, it may cause damage;
4.Please keep the battery dry;
5.Do not place it in extremely temperatures;
6.Do not try to disassemble the battery;
7.This device does not mean to be used as a nicotine replacement therapy for smoking cessation.
This refillable electronic cigarette is intended for use with compatible liquid, which may contain nicotine. Nicotine is
an addictive substance and its use is not recommended for use by the following:
- Non smokers or persons under the legal smoking age
- Pregnant or breastfeeding women
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat
disease or difficulty breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal gland that
can affect blood pressure)
- Those taking the medications Theophylline, Ropinirole or Clozapone
You may experience the following side effects if you use nicotine containing e-liquid in combination with this
product. If this happens, please consult a healthcare professional and show them this leaflet if possible:
- Feeling faint
- Nausea
- Dizziness
- Headache
- Coughing
- Irritation of the mouth or throat
- Stomach discomfort
- Hiccups
- Nasal congestion
- Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the age of 18 or non-smokers.
Designed in California
Manufacturer:Shenzhen Smoore Technology Limited
Add:Building 8,Dongcai Industrial Park,Gushu Town,
Baoan District,Shenzhen, China 518102
Management System of SMOORE factory has been assessed
and registered under the Norm cGMP, ISO13485, ISO9001
and ISO14001.TM and ©2016 Vaporesso All rights reserved
