Pan sensor function
This activates automatically if a pan is
not placed on the cooking zone within 2.5
seconds from when it was switched on.
The symbol appears on the display.
GB
Booster function
Select the cooking zone and then press the
Booster button to enter this operating mode.
The letter "P" appears on the display the
power of the zone increases from rated
power to a higher power for 5 minutes:
Ø200 - from 2300 to 3000W.
This function may terminate ahead of time
if:
- If you touch the slider area after selecting
the cooking area with the "P".
- If the temperature of the zone or system
is too high
- If the pan is removed for more than 10
minutes
Automatic heat-up function
When the automatic heat-up function
is activated the wattage of the cooking
zone is at 100% for a certain heat-up time
which is dependent on the setting selected
(continuous).
At the end of the heat-up time the electronic
control switches back to the preselected
simmering setting.
Starting process of the automatic heat-
up
- The control is ON and a cooking zone will
be selected
- When the power level 9 is reached
the automatic
through a further press of the slider in
correspondence with the maximum value.
- The required power level is selected by
means of the slider and the selected
heating is activated
value is shown on the display.
- At this point, you can select the level
required for the continuation of the
cooking using the Slider area. The symbol
"A" appears 3 seconds after the button is
released, alternating with the continuation
level.
- The continuation level can be changed
within 15 seconds from activation without
disabling the precooking boost. So, you
must select the cooking area and then set
the corresponding cooking area.
- If the selection takes place after 15
seconds:
You can select a higher continuation level;
this implies that the precooking time will
automatically be aligned to the currently
selected continuation level.
Table
Precooking
Cooking
level
0
1
2
3
4
5
6
7
8
9
Residual heat indicator
It is meant to indicate to the user that the
glass ceramic has a dangerous touch
temperature in the circumference of a
cooking zone. The temperature will be
determined following
model and the remaining residual heat
28
Maximum
Boost A operating
[min] time [h]
0 0
1 6
3 6
4,8 5
6,5 5
8,5 4
2,5 1,5
3,5 1,5
4,5 1,5
0,2 1,5
a mathematical
