LaserJet Pro M101-M104,
LaserJet Ultra M105-M106
Getting Started Guide
IMPORTANT:
Steps 1 - 3
First, follow
on the printer hardware
setup poster, then continue
with
Step
4.
5. Select a connection method
USB connection directly between the
printer and the computer
Use an A-to-B type USB cable.
Windows
1.
For Windows 7 or lower, do not connect the USB cable before installing
the software. The installation process prompts to connect the cable at
the appropriate time. If the cable is already connected, restart the printer
when installation prompts to connect the cable.
2.
Continue to
"6. Locate or download the software installation files."
NOTE: During Windows software installation, select the option to connect
through a network.
Mac
1.
Connect the USB cable between the computer and the printer before
installing the software.
2.
Continue to
"6. Locate or download the software installation files."
Wired (Ethernet) network connection
(optional)
Use a standard network cable.
1.
Connect the network cable to the printer and to the network. Wait a few
minutes for the printer to acquire a network address.
2.
Continue to
"6. Locate or download the software installation files."
NOTE: During software installation, select the option to Connect through
a network.
*G3Q34-91006*
*G3Q34-91006*
G3Q34-91006
www.hp.com/support/ljM101
4. Set up the control panel
At the printer control panel, check the LED status before beginning software installation.
www.register.hp.com
Perform a wireless installation
(wireless models only)
Before starting the installation, verify that the wireless access point is working
correctly. Make sure that the printer, router, and computer are all turned on
and that the computer is connected to the same wireless network that the
printer will be connected to.
If there is not a solid blue light on the top of the printer, go to Process A.
If there is a solid blue light on the top of the printer, go to Process B.
Process A
1. Place the CD in the CD-ROM drive, and then click Install. When the
Printer connections dialog appears, choose Configure to print over
the Wireless Network.
2. Follow the on-screen instructions.
Process B
1. Place the CD in the CD-ROM drive, and then click Install. When the
Printer connections dialog appears, choose Connect to a configured
Wireless Network printer.
2. Follow the on-screen instructions.
3. Select the printer detected by the software. If the printer cannot be
detected by the installer, manually input the printer's IP address to
continue the installation.
NOTE: Print a configuration page to find the printer's IP address. At the
printer control panel, press and hold the Resume/Cancel button for
5 seconds, and then release the Resume/Cancel button to print the
configuration page. The IP address is listed on the configuration page
in the Network Information section.
Manually configure the IP address
See the printer user guide for information on how to manually configure the
IP address www.hp.com/support/ljM101.
2
English .............. 1
Français ............ 4
Español ............. 7
Português ....... 10
............... 13
Publicidad
Manuales relacionados para HP LaserJet Pro M101
Resumen de contenidos para HP LaserJet Pro M101
- Página 1 LaserJet Pro M101-M104, English ....1 Français .... 4 LaserJet Ultra M105-M106 Español ..... 7 Getting Started Guide Português ..10 ....13 www.hp.com/support/ljM101 www.register.hp.com IMPORTANT: Steps 1 - 3 First, follow 4. Set up the control panel on the printer hardware setup poster, then continue At the printer control panel, check the LED status before beginning software installation.
-
Página 2: Install The Software
Menu button. Select Print, select the printer, and select Print. Enable Wi-Fi Direct Enable HP Web Services in the HP Embedded Web Server (EWS) by following Some devices require downloading the HP Print Service plugin app from the Google Play store. - Página 3 Set up HP ePrint via email (optional) Use HP ePrint via email to print documents by sending them as an email attachment to the printer’s email address from any email enabled device, even from devices that are not on the same network.
-
Página 4: English
« 6. Localiser ou télécharger les fichiers d’installation du logiciel ». REMARQUE : Lors de l’installation du logiciel, sélectionnez l’option Se connecter via un réseau. Configurer manuellement l’adresse IP Consultez le Guide de l’utilisateur de l’imprimante pour obtenir des informations sur la configuration manuelle de l’adresse IP www.hp.com/support/ljM101. -
Página 5: Installer Le Logiciel
Menu. Sélectionnez Imprimer, puis l’imprimante Activer Wi-Fi Direct et appuyez sur Imprimer. Activez les services Web HP dans le serveur Web intégré (EWS) HP en Pour certains périphériques, il est nécessaire de télécharger l’application du procédant comme suit : module d’extension du service d’impression HP sur Google Play. - Página 6 Configurer HP ePrint via messagerie électronique (facultatif) Utilisez HP ePrint via messagerie électronique pour imprimer des documents en les envoyant en pièce jointe à l’adresse électronique de l’imprimante depuis n’importe quel périphérique activé, même ceux qui ne sont pas sur le même réseau.
-
Página 7: Www.rEgister.hP.cOm
Información de la red de la página de configuración. NOTA: Durante la instalación del software, seleccione la opción Conectar a través de una red. Configuración manual de la dirección IP Consulte la Guía del usuario de la impresora para obtener información sobre cómo configurar manualmente la dirección IP www.hp.com/support/ljM101. -
Página 8: Localización O Descarga De Los Archivos De Instalación Del Software
HP Easy Start. Siga las instrucciones en pantalla para instalar el software. Abra la utilidad HP Easy Start y siga las instrucciones que se muestren Cuando se le indique que seleccione un tipo de conexión, seleccione la en la pantalla. -
Página 9: Solución De Problemas
Configuración de HP ePrint a través del correo electrónico (opcional) Utilice HP ePrint a través del correo electrónico para imprimir documentos enviándolos como adjunto de un mensaje de correo electrónico a la dirección de correo de la impresora desde cualquier dispositivo que tenga acceso al correo electrónico, incluso desde dispositivos que no están en la misma red. -
Página 10: Configurar O Painel De Controle
NOTA: Durante a instalação do software, selecione a opção para Conectar-se por meio de uma rede. Configurar manualmente o endereço IP Consulte o guia do usuário da impressora para obter informações sobre como configurar manualmente o endereço IP www.hp.com/support/ljM101. -
Página 11: Instalar O Software
Usuários do Mac podem clicar no link no CD ou acessar diretamente instalação de software baixado da Web. 123.hp.com e baixar o HP Easy Start para instalar o software da impressora. O instalador do software detecta o idioma do sistema operacional Acesse 123.hp.com. -
Página 12: Configurar O Hp Eprint Por E-Mail (Opcional)
Configurar o HP ePrint por e-mail (opcional) Use o HP ePrint via e-mail para imprimir documentos enviando-os como um anexo de e-mail para o endereço de e-mail da impressora de qualquer dispositivo compatível com e-mail, mesmo de dispositivos que não estejam na mesma rede. -
Página 13: Tabla De Contenido
English ....1 Français .... 4 Español ..... 7 Português ..10 ....13 www.hp.com/support/ljM101 www.register.hp.com... -
Página 16: Fcc Regulations
The information contained herein is subject to change without notice. Les informations contenues dans ce document peuvent être modifiées sans préavis. The only warranties for HP products and services are set forth in the express Les seules garanties pour les produits et services HP sont décrites dans les warranty statements accompanying such products and services.
