Troubleshooting - Rena Ware AQUA NANO CTU-100 Uso Y Mantenimiento

2. Remove the battery compartment door in the bottom of the base by unscrewing
the two screws and by gently prying the door open using a flat screwdriver.
3. Remove the old batteries, wait 20 seconds, and then replace with two new, high
quality, AA batteries with an expiration date of at least one year beyond the day of
installation. This will reset the flow meter to "0" and the LED lights will start flashing
again when water is flowing through the filter.
4. Install a new cartridge and charge it. (See "SETUP" section).
5. Run water for 2 minutes to remove any carbon particles and expel trapped air.
18

TROUBLESHOOTING

Water is not coming out of the wand.
•
Turn the diverter valve to the "on" position.
•
Make sure the tubing is smooth and straight, without kinks.
Water leaks out of between filter cartridges or at the filter inlet assembly or filter
base.
•
Separate the cartridges at the point of the leak. Each of the cartridges, and the
filter inlet, should have two o-rings on the raised outlet found on the bottom of
the cartridge. Check to ensure that the o-rings are in place and properly seated in
the grooves provided for them.
Water leaks from the tubing.
•
Check the tubing for cuts or nicks.
Water continues to flow out of the wand after water is turned off.
•
Water may continue to flow from the wand for a short time due to a build-up
of pressure within the filter. It will typically stop by itself. You may also turn the
diverter valve lever to the off position to activate your tap water faucet, which will
reduce water coming from the wand.
•
Trapped air in the filter may force water out after the tap has been turned off.
To eliminate trapped air, follow the steps listed under the topic "CHARGING THE
SYSTEM".
Lights on the base do not work.
•
Make sure the batteries are properly installed. (See step 2 under "SETUP". )
The electronic flow meter stops functioning.
Reset the meter by using the following procedure:
1. Remove the battery compartment door in the bottom of the base by unscrewing
the two screws and by gently prying the door open using a flat screwdriver at the
point shown in the diagram. See "Replacing the NanoCeram® Cartridge" (step 2).
2. Remove the old batteries, wait 20 seconds, and then replace with two new high
quality AA batteries.
3. Replace the NanoCeram® filter cartridge, (see "Maintaining NanoCeram®
Cartridge" section). The unit will reset to its default settings.
19
