Adjusting The Handle; Securing Child - Baby Jogger city GO i-Size Manual De Instalación

CAR SEAT INSTALLATION WITHOUT BASE
10 Place Car Seat Rear-Facing in the Vehicle
Place the car seat on the vehicle seat. Push it back
until the front of the car seat touches the vehicle seat
back.
11 Put lap section of belt over car seat and under the two
belt hooks marked in blue. Buckle the vehicle belt.
12 Place shoulder belt around the back of the car seat
exactly as shown, making sure to run it through the
center guides on the back of the seat and below the
notch opposite the shoulder belt origin. The seat belt
should lay as flat as possible and not be twisted. Make
sure buckle and seat belt are in line with each other.
Contact Baby Jogger if in doubt about this point.
13 Tighten Vehicle Seat Belt
Lay your forearm across the car seat at the belt path
and push down. Pull on the shoulder belt to tighten
while feeding the slack back into the retractor.

ADJUSTING THE HANDLE

14 Squeeze latches on both sides at bottom of handle to
release it.
Rotate handle until it clicks into any of the 4 positions:
Position A (up): MUST be used when carrying by
handle,
Position B: Vehicle Travel Position
Position C: Convenience Position
Position D (down): is the sitting position.
Always place handle in the B position when using it in
a vehicle.

SECURING CHILD

15 Loosen Harness Straps
Push down on the harness release lever while pulling
out on the harness straps.
15
EN
