Maintenance Chart Machine Breakdown / Maintenance Chart - Stone Mud Buggy SB1600 Manual Del Operador

The person attempting any of the following
maintenance tasks must be authorized to do so and
have read and understood all sections within this
manual.
MAINTENANCE CHART MACHINE BREAKDOWN
M7 M7 M7 M7 M7
E7 E7 E7 E7 E7
E1 - E6 E1 - E6 E1 - E6 E1 - E6 E1 - E6
M4 M4
M4 M4 M4
Check/Adjust
o
Clean/Replace
ENGINE
E1 Oil Level
E2 Air Filter & Pre-cleaner
E3 Spark Plug
E4# Engine RPM Idle/Full
E5 Clean Cooling System
E6## Valve Clearance
E7 Fuel Tank
MACHINE
Hydraulic Oil Level
M1
Hydraulic Filter
M2
Hydraulic Breather
M3
Wheel Hubs
M4
Rear Steering Column
M5
M6 Hopper Pivot/Dump Cylinder
Control Cable
M7
Battery/Charge System
M8
# Important READ Engine Emissions Warranty Statement, Manual and Engine Manual
## See AUTHORIZED Engine Service Dealer and/or Refer to Engine Shop Manual for Procedures
IMPORTANT!
M3 M3 M3 M3 M3
M2 M2
M2 M2 M2
M1 M1 M1 M1 M1
M6 M6 M6 M6 M6
M8 M8
M8 M8 M8
M5 M5 M5
M5 M5
READ EMISSION WARRANTY, OPERATOR &
ENGINE MANUAL
Replace at 50-hrs, then every 100-hrs SAE 30W AP, SH
o
or SJ
Clean every 50-hrs, replace every 300-hrs
o
Clean every 100-hrs, gap setting .028 inch, replace
o
every 300-hrs
Check idle at full speed RPM every 300-hrs
Clean/blow out air inlets, engine fins (30 psi max)
o
Check/adjust every 300-hrs
Clean every year or 300-hrs
o
Replace every 200-hrs Mobil 424
o
Replace every 100-hrs (PN 45150)
o
Replace every 800-hrs (PN 38521)
o
Repack yearly with Wheel Bearing Grease
o
Lube weekly with Lithium Base Grease
o
Check operation, lube pivots weekly with Lithium Base
o
Grease
Check operation, lube cable every 50 hrs, light oil
o
Check/clean monthly/check for 13-14 volts at full RPM
o
Instructions
Maintenance
MUD BUGGY
51
