6-5. CHASSIS (KP-53SV85T)

7-685-648-79 SCREW +BVTP 3X12
4-081-063-01 SCREW, DOME WASHER
HEX TAPPING (4X20)
128
127
REF.NO. PART NO. DESCRIPTION
127 1-544-849-11 SPEAKER (13CM)
128 1-529-403-11 SPEAKER (6.6CM)
* 129 A-1298-990-A A BOARD, COMPLETE
130 8-598-430-50 TUNER, FSS BTF-FA401
131 8-598-431-20 TUNER, FSS BTF-WA411
* 132 1-557-056-31 CABLE, P-P
133 1-556-945-21 CABLE, P-P
! 134
8-598-414-20 CHANGER, ANTENNA AS-2F
135 4-069-675-01 CAP, TERMINAL BOARD
! mark are critical for safety.
133
128
— 62 —
NOTE: Les composants identifi es per un trame et une marque
pour la securite. Ne les remplacer que par une piece portant le numero specifi e.
135
134
132
131
142
130
129
127
REF.NO. PART NO.
! 136
4-069-674-12
* 137 A-1316-479-A
! 138
1-453-238-31
! 139
1-900-249-96
! 140
1-779-095-23
! 141
1-783-838-71
142 1-500-021-11
* 143 A-1241-390-A
KP- 43T85T / 53SV85T / 61SV85T
! sont critiques
136
140
137
139
138
143
141
DESCRIPTION
TERMINAL BOARD
G BOARD, COMPLETE
The high voltage leads associated with the FBT on this board are not
included and must be ordered separately (see 139-140).
FBT ASSY, NX-4007//X4P4
HARNESS ASSY, FOCUS PACK -2
LEAD ASSY, HIGH-VOLTAGE
CORD, POWER (WITH CONNECTOR)
CLAMP, SLEEVE FERRITE
FA BOARD, MOUNTED
