55. Auxiliary 1 and 2 Controls (Faders)
These controls alter the audio level that will be sent to the aUX
outputs, suitable for connecting to floor monitors, as well as
external processing devices, if required. The corresponding aFl
(after-Fader listen) buttons allow you to send the audio of the
auxiliary mixing bus to the cTRl RM/PHONES control, after being
altered by the corresponding fader (ie. after-fader). activation of
the aFl is accompanied by an illuminated lED.
56. Mono Output Controls
The Mono Channel fader will adjust the final audio level that is to
be sent to the Mono output jack. The corresponding aFl (after
Fader listen) button allows you to send the post-fader mono
audio signal to the cTRl RM/PHONES control.
The corresponding low Pass Filter controls, not featured on the
1860 Plus, are used to reduce unwanted high frequency sounds
of the mono output at a rate of 18 dB per octave, for a clearer
bass sound when using subwoofers. The switch turns the low
Pass Filter on and off, where the accompanying control adjusts
the minimum cut frequency between 60 and 160 Hz.
55
57. Master Level Control
This fader controls the final volume level of the Main L/R audio to
be sent to the built-in power amplifier and respective outputs.
58. Power Indicator
The Power Indicator, located next to the PFl/aFl indicator, will
light up when the power of the Powerpod K-12 Plus, K-16 Plus or
1860 Plus is on.
59. PFL/AFL Indicator
The PFl/aFl indicator on the top of this meter is bi-colored, and
illuminates green when a PFl switch is active and red for an aFl.
Due to the fact that any PFl has priority over any aFl, if both
an aFl and PFl are activated, only the green PFl indicator will
illuminated and processed by the cTRl RM/PHONES control
area.
8
Powerpod 1860 Plus
56
56
60. Limiter Indicators
There are 2 limiters built-in the stereo power amplifier featured in
the Powerpod K-12 Plus, K-16 Plus and 1860 Plus. The limiters
are activated and the indicator will illuminate when the Power
amplifier's signal level becomes too high, warning the user of
the possibility of overload. If this happens too often, ensure
you to turn down the corresponding input level control for the
Power Amplifier's source, as selected by the Power Amp Control
switches, to a reasonable level.
61. Stereo Level Meter
This level meter offers a visual display of the stereo Main l/R
output level. Each channel's 12-segment level meter consists of
green, yellow and red colored lEDs, including a peak indicator,
showing levels between -30dBu and +10dBu. When either a PFl
or aFl is activated, the master level meter offers a visual display
of the signal level of the PFl or aFl, monitored on the same
aspects as the level meter normally would. See the control Room
/ Phones section (54) for a little more information on PFls and
aFls.
57
POWERPOD 1860
59 58
60
61
/ K-12
/ K-16
