1. Restore electrical power to the outlet box by turning the
electricity on at the main fuse box. (Figure 17)
2. Install the fan pull chain coupler. (Figure 18)
3. Check the operation of the fan by gently pulling
on the pull chain switch. (Figure 19) Your fan model is
equipped with a 4-position, 3-speed, pull chain switch.
The operating sequence is as follows:
1st Pull = HIGH
2nd Pull = MEDIUM
4. If airflow is desired in the opposite direction,
turn the fan off and wait for the blades to stop
turning. Then slide the reverse switch to the
opposite position and turn fan on again.
(Figure 20)
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the nish.
Abrasive cleaning agents are not required and should be
avoided to prevent damage to nish.
RECOMENDED: Periodically check that the blade arm to motor assembly hub screws are tight.
Periodic light dusting of the Palm Leaf, Woven Bamboo,
or Wicker blades is recommended. A feather duster will
work best.

Operating Instructions - Pull Chain

3rd Pull = LOW
4th Pull = OFF

Maintenance

Blade Cleaning

CAUTION
Do not use solvents when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of electrical shock.
Avoid using water, cleansers, or harsh rags, which can
warp and ruin the blades.
10
Figure 17
Figure 18
Figure 19
Figure 20
