Name of each part

6
5
3
7
8
4
2
3
4
5
6
5
* Optical sensor: Measures moving distance by the light pattern which is reflected from floors and
comes into the optical receiver.
1
2
6
8
14
9
10
11
12
13
Top
2
1

1. Display panel

4
2. Remote control signal receiver
3. Obstacle sensor
2
4. Dustbin
5. Camera
6. Dustbin button
7. Bumper sensor
8. Auto shutter tool
Bottom
11
1. Charge pins
8
2. Brush
1
3. Brush cover
4
4. Cliff sensor
5. Roller
9
6. * Optical sensor
7. Battery cover
7
8. Brush cover button
10
9. Driving wheel
10. Emergency switch
11. Auto shutter tool
Display panel
3
4
1. Mute
5
2. Information Indicator
7
3. Remote control Off/On indicator
4. Wi-Fi
5. Battery indicator
6. One-time/Daily schedule
7. Number display
8. Spot clean mode
16
9. Manual clean mode
10. Repeat clean mode
11. Quiet mode
15
12. Normal mode
13. Turbo mode
14. Spot cleaning button
15. Start/Stop button
16. Recharging button
ENGLISH-20
