Product Assemblies
PSW-HANDLE9
PSW-HANDLE10
PSW-HANDLE12
PSW-HANDLE15
Parts Included
A. Handle (1)
B. Handle Screws
A
B
Tools Required
• Phillips Head Screwdriver
2700 Oak Industrial Drive NE, Grand Rapids, MI 49505 USA
800.253.1561 • 616.459.3311 • www.kv.com
HANDLE KIT
Installation Instructions
Inspect all parts and read all instructions prior to
beginning assembly and installation.
Follow these steps for PSW-HANDLE9, PSW-HANDLE10, PSW-HANDLE12
and PSW-HANDLE15 product assemblies.
Extend the slide members of the waste bin product assembly out of the
1
cabinet interior to a comfortable working position. Select a side to begin
assembly. Position the handle on the inside of the slide member, aligning
the holes (A).
Attach the handle to the slide member using the handle screws provided.
Tighten screws to secure handle in place. Repeat the process attaching the
handle to the opposite side slide member. Installation is now complete.
Installed handle should look like figure B.
A
©2009Knape & Vogt. All rights reserved. Knape & Vogt
B
reserves the right to change specifications without notice. Made in USA.
®
310171 (0912)
