VSky H3970 Quick Start Guide
t 3: I
ask nsert
Follow the instructions below to first remove the chassis cover, then you can unpack the HDDs
in the disk trays and insert them into available bays in the VSky H3970 enclosure. Finally you can
replace the chassis cover to complete the HDD assembly insertion procedure.
Remove the chassis cover
1. Release the screw on the top front chassis cover.
2. Slide the front cover horizontally to the front and remove it along the direction of the arrow.
Remove the Top Front Chassis Cover
3. Loosen the screws on the top rear chassis cover.
4. Slide the rear cover horizontally to the front and remove it along the direction of the arrow.
Remove the Top Rear Chassis Cover
hdd
s
7
