4. Fuse Replacement Instructions
(refer to images in front)
1. CAUTION: Unplug the Accelerator from
the outlet.
2. Use a Phillips head screwdriver to remove the screw at
the bottom of the Power Supply housing. Set the screw
aside for reassembly.
3. Remove the door from the housing.
4. Pull out the white power cord from its connection and
let it hang freely. (see figure 4.1)
5. Look for the fuse label near the upper, right-hand side
to identify the fuse location. (see figure 4.1)
6. Using a small, thin bladed, flathead screwdriver, pry
open the right-hand side of the fuse door. Then pry out
the red fuse rack. (see figures 4.2-4.3)
5. Trouble Shooting Guide
Problem Causes
Display reads • One of the cables between power
SYSTEM ERROR CALL pack and Accelerator head not plugged in
CUSTOMER SERVICE
Display reads • New Light guide was first placed on
*GUIDE STATUS* Zoom Advanced Power or older system
IMPROPER GUIDE
Display reads • One or more sessions was interrupted by
*GUIDE STATUS* the off button
REPLACE GUIDE
• One or more sessions was interrupted by
before the guide is empty
a power outage
• One or more sessions was interrupted
by light guide disconnection
Display reads • Light guide is not fully seated
*GUIDE STATUS* on the Accelerator head
ATTACH GUIDE
• Light guide was up on
When a guide is attached
upside down
• The pins on the underside of the
Accelerator head are damaged
7
7. Remove fuses from both sides of the red fuse rack – note
their location in the fuse rack. (see figures 4.4-4.5)
8. Snap in the new fuses at the top of the fuse rack, they
should be closer to the side with the tabs (top).
(see figures 4.4-4.5)
9. Reinsert the fuse rack into the fuse slot with the tabs first.
Push the fuse rack in until it is securely in place. You will
not be able to close the fuse door if the fuse rack is not
inserted correctly.
10. Close the fuse door.
11. Reinsert the power cord firmly into the housing.
12. Reinsert the screw into the door and tighten with a
Phillips head screwdriver.
Solution
Accelerator
Make sure all 3 connectors are plugged in (
head, back of the boom, into the power pack)
If error code remains, call customer service
Replace guide with a new guide that was not first
placed on a Zoom Advanced Power or older system
If One or more sessions is interrupted by any of the
3 causes listed, the lost session can not be recovered
Pull the light guide off and
reinstall correctly
Place the light guide on the Accelerator head
with the word TOP facing up
Call Customer service for a
Accelerator head replacement
6. Specifications
Philips Zoom! WhiteSpeed Whitening LED Accelerator
Input Ratings 100-240V~, 3A, 50-60 Hz
Classification Class 1 Type BF, IPXO, Equipment not suitable for use in the presence of flammable mixtures
Operating Mode Continuous
Operating Temperature 10ºC - 40ºC (50ºF - 104ºF)
Light Source LED Array
Bandwidth 400 - 505 nanometers normal
Cooling Air Cooled
Height 136cm / 53.5 in
Weight 11 kg / 24 lbs
Guidance and manufacturer's declaration – electromagnetic emissions
The Zoom WhiteSpeed, Dental Teeth Whitening Lamp is intended for use in the electromagnetic environment specified below. The
customer or the user of the Zoom WhiteSpeed should assure that it is used in such an environment.
Emissions Compliance Electromagnetic environment – guidance
RF emissions Group 1 The Zoom WhiteSpeed uses RF energy only for its internal function. Therefore, its RF emissions are very low
and are not likely to cause any interference in nearby electronic equipment.
CISPR 11
The wireless transmitter in the foot pedal is battery powered only, and does not connect to public mains.
RF emissions Class A
CISPR 11 The Zoom WhiteSpeed is suitable for use in all establishments other than domestic and may be used in
domestic establishments and those directly connected to the public low-voltage power supply network that
Power Line Harmonics Class A
supplies buildings used for domestic purposes, provided the following warning is heeded:
IEC/EN 61000-3-2
Warning: This equipment/system is intended for use by healthcare professionals only. This equipment/system
may cause radio interference or may disrupt the operation of nearby equipment. It may be necessary to take
Power Line Flicker Complies
mitigation measures, such as re-orienting or relocating the Zoom WhiteSpeed or shielding the location.
IEC/EN 61000-3-3
