INTRODUCTION

Congratulations on your purchase of the Sound
Ambassador expansion speakers for the Sound
Ambassador Deluxe Portable PA Systems� Available
in passive and active models, the Sound Ambassador
expansion speakers transform your single speaker
Sound Ambassador PA system into a 2, 3 or 4 speaker
system, depending on your needs� There are limitless
setup possibilities with the addition of one or more of
these expansion speakers�

FEATURES

Active Models
Sound Ambassador 40A
 6�5" full range speaker with 35 Watt power
amplifier
 2�7Ah acid-lead battery built-in, operates on DC or
AC power
 25mm diameter tripod stand adapter included
 Speaker output jack for external passive speaker
(Sound Ambassador 40P)
Sound Ambassador 80A
 10" 2-way speaker system with 75 Watt power
amplifier
 Frequency response: 50Hz to 18kHz
 100-240VAC switching power supply
 Built-in DC charging circuit
 24V DC supply from two built-in, maintenance-free
lead acid type rechargeable batteries
 24-32VDC inlet for external power supply
 Two 1/4" phone jacks for input & output
 Built-in limiter and protection circuitry to minimize
distortion and overload
 Tripod stand adapter included
Sound Ambassador 125A
 10" 2-way speaker system with 120 Watt power
amplifier
 Frequency response: 50Hz to 18kHz
 100-240VAC switching power supply
 Built-in DC charging circuit
 24V DC supply from two built-in, maintenance-free
lead acid type rechargeable batteries
 24-32VDC inlet for external power supply
 Two 1/4" phone jacks for input & output
 Built-in limiter and protection circuitry to minimize
distortion and overload
 Tripod stand adapter included
4
Passive Models
Sound Ambassador 40P
 Passive expansion speaker for the Sound
Ambassador 35 Deluxe
 6�5" full range speaker with 40 Watt power handling
(program)
 Sensitivity: 92 dB SPL @ 1W / 1m
 25mm diameter tripod stand adapter included
Sound Ambassador 80P
 Passive expansion speaker for the Sound
Ambassador 75 Deluxe
 10" 2-way speaker system with 150 Watt power
handling (program)
 Frequency response: 50 Hz to 18 kHz
 Sensitivity: 96dB SPL @ 1m
 Two 1/4" phone jack for input & output
 Tripod stand adapter included
Sound Ambassador 125P
 Passive expansion speaker for the Sound
Ambassador 120 Deluxe
 10" 2-way speaker system with 240 Watt power
handling (program)
 Frequency response: 50 Hz to 18 kHz
 Sensitivity: 96dB SPL @ 1m
 Two 1/4" phone jack for input & output
 Tripod stand adapter included
Sound Ambassador 40A / 40P / 80A / 80P / 125A / 125P
