Electrical; Physical - Digital Projection TITAN 600 Serie Información Importante

Digital Projection TITAN 1080p-600, sx+600, HD-600, Reference 1080p
Lamp power
Lamp life (typical)
Brightness
Colour temperature

Electrical

Inputs
Pixel clock
Control inputs
Indicators
Mains voltage
Power consumption
International Regulations

Physical

Operating Temperature
Storage Temperature
Thermal Dissipation
Operating Humidity
Weight
Rev A March 2008
2 x 300W
2000 hours in dual lamp mode , 4000 in single lamp mode
1080p-600: 10,000 ANSI lumens (±10%) in dual lamp mode
Reference 1080p: 4,000 ANSI lumens (±10%) in dual lamp
mode
sx+600: 11,000 ANSI lumens (±10%) in dual lamp mode
HD-600: 8,000 ANSI lumens dual lamp mode
Native: 7500°K (±1000°K),
White balance adjustment: 3000°K - 10000°K
RGB1, RGB2, DVI, Composite Video, S-Video, Component.
sx+ and 1080p only: and SDI
up to 165MHz
1 x LAN
1 x wifi LAN (FCC ID: R68WIPORT)
1 x RS232 serial: 19200 baud, 8 bits, 1 stop bit, no parity
1 x remote control
Input, Power, Shutter, Error, IR, Lamp 1, Lamp 2
100-230 VAC ±10%, 48-62Hz (single phase)
850W
Meets FCC Class A requirements
Meets EMC Directives (EN 55022, EN 55024, EN 55103)
Meets Low Voltage Directive (EN60950)
0 to 40°C
-10 to 50°C
2900 BTU/hr
20% to 80% non-condensing
approximately 31 kg (68 lbs)
FCC WIFI ID, R68WIPORT
English
Page 9
