System Map: Bottom View

2
2
3
10
1
2
2
2
Figure 4
Bottom View
1. Battery
2. Vent
2
3. Speakers
To prevent your computer from
overheating make sure nothing
blocks any vent while the computer
is in use.
3
Bottom Cover Removal Warning
Do not remove any cover(s) and/or
screw(s) for the purposes of device
upgrade as this may violate the
terms of your warranty.
If you need to replace/remove the
HDD/SSD/RAM etc., for any rea-
son, please contact your distributor/
supplier for further information.

Overheating
