Connecting an AV Equipment with DVI Connector

HDMI IN HDMI IN
AUDIO
L R
L R
VIDEO AUDIO
VIDEO IN
HDMI-to-DVI Cable

Use a HDMI-to-DVI cable to connect the AV equipment's DVI output jack to the LCD TV's
HDMI1/HDMI2 IN jacks.
Use an audio cable to connect the
AUDIO jacks.

Connect all AC power sources, before turning on the power switch of the LCD TV or
other connected equipment.

Press the

Press the SOURCE button on the remote to select VIDEO or VIDEO .
If the LCD TV is connected to AV equipment's DVI connector, you will need
a HDMI-to-DVI cable or a HDMI adaper (not included).
