Digital ADAS 2.0
Installation manual
Digital ADAS CPU configuration using
the scantool
1 Take the scantool
2 Open the Digital ADAS Settings menu
page on the scantool
3 Press the button indicated in the
image when prompted
4 Set some parameters:
a. Test Type = Axis of symmetry (set
by default), allows you to perform
the calibration using the clips on
the front wheels. (Note: It is pos-
sible to select Direction axis only if
you want to carry out the calibra-
tion according to the requirements
of the French CESVI, using the
clips on the rear wheels)
b. TV model = 3
c. Bar model = 2
d. Laser model = 2
e. Strip model = 2
f. Radar target model = 3
g. Remote control model = 2
h. Camera
5 The configuration is finished and the
2 symbols of the laser meters will be
displayed
The numbers to be reported in the
settings are placed with adhesive
on the back of each component.
The vertical remote control setting
is visual, depending on the remote
control in your possession.
