INSTALLATION INSTRUCTIONS
Air Conditioner
This air conditioner uses the refrigerant R410A.
Model No.
Outdoor Units
Type Outdoor Unit Type
LE2 mini VRF System
• To be connecting Indoor Unit
Indoor Units
Type
Indoor Unit Type
D1
1-Way Cassette
L1
2-Way Cassette
U2
4-Way Cassette
Y2
4-Way Cassette 60 × 60
K2
Wall-Mounted
T2
Ceiling
F2
Low Silhouette Ducted
M1 Slim Low Static Ducted
P1
Floor Standing
R1
Concealed Floor Standing
Type
Indoor Unit Type
D1
1-Way Cassette
L1
2-Way Cassette
U2
4-Way Cassette
K2
Wall-Mounted
T2
Ceiling
F2
Low Silhouette Ducted
P1
Floor Standing
R1
Concealed Floor Standing
Read through the Installation Instructions before you proceed with the installation. In particular, you will need to read under
the " IMPORTANT ! " section at the top of the page.
HP = horsepower
Rated Capacity
4 HP
5 HP
U-4LE2E5
U-5LE2E5
U-6LE2E5
U-4LE2E8
U-5LE2E8
U-6LE2E8
15
22
S-22ML1E5
S-22MU2E5A S-28MU2E5A S-36MU2E5A S-45MU2E5A S-56MU2E5A S-60MU2E5A
S-15MY2E5A S-22MY2E5A S-28MY2E5A S-36MY2E5A S-45MY2E5A S-56MY2E5A
S-15MK2E5A S-22MK2E5A S-28MK2E5A S-36MK2E5A S-45MK2E5A S-56MK2E5A
S-15MF2E5A S-22MF2E5A S-28MF2E5A S-36MF2E5A S-45MF2E5A S-56MF2E5A S-60MF2E5A
S-15MM1E5A S-22MM1E5A S-28MM1E5A S-36MM1E5A S-45MM1E5A S-56MM1E5A
S-22MP1E5
S-22MR1E5
71 / 73
90
S-73MD1E5
S-73ML1E5
S-73MU2E5A S-90MU2E5A S-106MU2E5A S-140MU2E5A S-160MU2E5A
S-73MK2E5A
S-73MT2E5A
S-73MF2E5A S-90MF2E5A S-106MF2E5A S-140MF2E5A S-160MF2E5A
S-71MP1E5
S-71MR1E5
6 HP
Rated Capacity
28
36
S-28MD1E5
S-36MD1E5
S-45MD1E5
S-28ML1E5
S-36ML1E5
S-45ML1E5
S-36MT2E5A S-45MT2E5A S-56MT2E5A
S-28MP1E5
S-36MP1E5
S-45MP1E5
S-28MR1E5
S-36MR1E5
S-45MR1E5
Rated Capacity
106
140
S-106MK2E5A
S-106MT2E5A S-140MT2E5A
45
56
60
S-56MD1E5
S-56ML1E5
S-56MP1E5
S-56MR1E5
160
ACXF60-27630
