FALGAS 60’s SURF VAN Manual Del Usuario página 25

60's Surf Van
2.3- CÓDIGOS MECANISMO JUEGO · GAME MECHANISM CODES
.
166 TORNILLO M5x12 DIN-912
254 ARANDELA ø 3 DENTADA DIN-6798A
257 ARANDELA ø 4 DENTADA DIN-6798A
260 ARANDELA ø 5 ANCHA DIN-9021
264 ARANDELA ø 6 ANCHA DIN-9021
1150 COJINETE 6001-2RS ø28xø12x8
1825 MICRO VARILLA 83.137.5 I W3
2734 TORNILLO M6x16 DIN-933
3031 TUERCA M3 DIN-934
3032 TUERCA M4 DIN-934
3034 TUERCA M4 FRENO DIN-985
3035 TUERCA M5 DIN-934
3038 TUERCA M6 DIN-934
5155 ARANDELA ø 4 GROWER DIN-127
5156 ARANDELA ø 5 GROWER DIN-127
12784 REMACHE ROSCADO M4
15084 TORNILLO M4x12 DIN-7985
16016 TORNILLO M4x16 ISO-7380-10.9
20763 ARANDELA ø 6 GROWER DIN-127
20877 ARANDELA ø 4 ANCHA DIN-9021
21776 MOTOR REDUCTOR KELVIN K30-37.62 12Vcc 562.56:1
25305 TORNILLO M3x25 DIN-84
30169/C IMAN SURF VAN JUEGO
33124 CIRCLIP I-28 DIN-472
32125 ESPARRAGO ALLEN M4x10 DIN-913
33335 BOLA JUEGO SURF VAN
33869 TAPA PLÁSTICO ¼ GRANDE –IZQUIERDA + CALCA
33870 TAPA PLÁSTICO ¼ GRANDE –DERECHA + CALCA
33871 TAPA PLÁSTICO ¼ PEQUE –IZQUIERDA + CALCA
33872 TAPA PLÁSTICO ¼ PEQUE –DERECHA + CALCA
33873 TAPA PLÁSTICO REDONDA CENTRO + CALCA
33874 PLASTICO FIGURA SURFER + CALCA
33883 DISCO MECANISMO JUEGO SURF VAN
33884 SOPORTE EJE I MICROS JUEGO SURF VAN
33885 RAMPA SUBIDA FIGURAS JUEGO SURF VAN
33886 EJE FIGURA TIBURÓN JUEGO SURF VAN
33887 ANGULO SOPORTE MODULO JUEGO SURF VAN
33888 RESORTE FIGURAS TIBURÓN JUEGO SURF VAN
33889 TORNILLO ø2,2x9,5 DIN-7981-C
33890 PLANCHA SOPORTE MECANISMO JUEGO SURF VAN
33891 CHASIS JUEGO SURF VAN
33892 SEPARADOR HEXAGONAL M4x12 DIN-6334
33893 FIGURA TIBURÓN JUEGO SURF VAN
34191 SOPORTE FIGURA SURFER
2.4- CÓDIGOS MODULO CANGREJO · CRAB MODULE CODES
257 ARANDELA M4 DENTADA DIN-6798A
262 ARANDELA M5 DIN-125
2719 TORNILLO M4x30 DIN-933
2721 TORNILLO M5x12 DIN-933
3034 TUERCA M4 FRENO DIN-985
5156 ARANDELA M5 GROWER DIN-127
5559 PASACABLE GOMA REF.317
18530 TORNILLO M4x8 ISO-7380 CROMADO
20364 ARANDELA M6 DENTADA DIN-6798A
20877 ARANDELA M4 ANCHA DIN-9021
31923 TORNILLO M6x45 DIN-912 CROMADO
33875 PLÁSTICO PINZAS CANGREJO ROJO
33876 PLÁSTICO PINZAS CANGREJO NARANJA
33877 PLÁSTICO CUERPO CANGREJO ROJO/A
33878 PLÁSTICO CUERPO CANGREJO ROJO/B
33879 PLÁSTICO CUERPO CANGREJO NARANJA/A
33880 PLÁSTICO CUERPO CANGREJO NARANJA/B
33894 BOBINA TACA-1 SURF VAN
33895 CHAPA SOPORTE PALANCA MODULO JUEGO
33896 PASADOR CALIBRADO Ø 4x11
33897 SEPARADOR HEXAGONAL M6x35
33898 PASADOR ELÁSTICO 2x12 DIN-1481
33899 ARANDELA GOMA Ø15x30x3mm
SCREW M5x12 DIN-912
LOCK WASHER ø 3DIN-6798A
LOCK WASHER ø 4DIN-6798A
WIDE WASHER ø 5 DIN-9021
WIDE WASHER ø 6 DIN-9021
BEARING 6001-2RS ø28xø12x8
WIRE MICROSWITCH 83.137.5 I W3
SCREW M6x16 DIN-933
NUT M3 DIN-934
NUT M4 DIN-934
LOCK NUT M4 DIN-985
NUT M5 DIN-934
NUT M6 DIN-934
GROWER WASHER ø 4 DIN-127
GROWER WASHER ø 5 DIN-127
SCREW BERYNUT M4
SCREW M4x12 DIN-7985
SCREW M4x16 ISO-7380-10.9
GROWER WASHER ø 6 DIN-127
WIDE WASHER ø 4 DIN-9021
MOTOR-REDUCER K30-37.62 12Vcc 562:1
SCREW M3x25 DIN-84
SURG VAN GAME MAGNET
CIRCLIP I-26
HEXAGON SOCKET SCREW M4x10 DIN-914
SURF VAN GAME BALL
PLASTIC COVER ¼ BIG-LEFT + STICKER
PLASTIC COVER ¼ BIG-RIGHT + STICKER
PLASTIC COVER ¼ BSMALL-LEFT + STICKER
PLASTIC COVER ¼ SMALL-RIGHT + STICKER
PLASTIC COVER ROUND CENTRE + STICKER
PLASTIC SURFER FIGURE/A + STICKER
SURF VAN GAME MECHANISM DISC
SHAFT AND SWITHS SUPPORT – S. VAN GAME
FIGURES RAMP – SURF VAN GAME
SHARK FIGURE SHAFT – SURF VAN GAME
ANGLE SUPPORT – SURF VAN GAME
SPRING SHARK FIGURE– SURF VAN GAME
SCREW ø2,2x9,5 DIN-7981-C
MECHANISM SUPPORT PLATE- S. VAN GAME
CHASSIS SURF VAN GAME
HEXAGON COUPLING NUT M4x12 DIN-6334
SHARK FIGURE SURF VAN GAME
SURFER FIGURE SUPPORT
LOCK WASHER M4 DIN-6798A
WASHER M5 DIN-125
SCREW M4x30 DIN-933
SCREW M5x12 DIN-933
BRAKE NUT M4 DIN-985
GROWER WASHER M5 DIN-127
RUBBER END REF.317
SCREW M4x8 ISO-7380 CHROME-PLATED
LOCK WASHER M6 DIN-6798A
WASHER M4 DIN-9021
SCREW M6x45 DIN-912 CHROME-PLATED
GRIPPER CRAB PLASTIC RED
GRIPPER CRAB PLASTIC ORANGE
BODY CRAB PLASTIC RED/A
BODY CRAB PLASTIC RED/B
BODY CRAB PLASTIC ORANGE/A
BODY CRAB PLASTIC ORANGE/B
SOLENOID TACA-1 REF.6380077
SUPPORT PLATE GAME LEVER
PIN Ø 4x11
HEXAGON COUPLING NUT M6x35
SPRING ROLL PIN 2x12 DIN-1481
RUBBER WASHER Ø15x30x3mm
.
25
