Establishing the connection
1 6 12 18
BL E G er ä te
BLE devices
CE 2 00 2 D
0 2 /0 5
∧ ∨
+
ESC
Fig. 23: Selecting the channel extension
7. On the DIN-rail timer, use the keys on the left (⋀/⋁) to select from the list the channel extension to be
connected, and confirm with
The connected channel extension is indicated by #.
8. Select a new channel extension with the keys on the left (⋀/⋁) and confirm with
1 6 12 18
C H 3
Ve rbunden : Connected:
TS 2 5 0 0 1
3 4 Menu
Fig. 24: Channel extension is connected to the DIN-rail timer
9. The channel extension displays the name of the connected device if there is an active connection
(Fig. 24/ ).
1
The display switches between the name of the connected device and the current date and time.
ð
After a connection is established, the channel name switches from "A" and "B" to "3" and
"4", "5" and "6" or "7" and "8".
10. If the DIN-rail timer or the channel extension is protected by PIN, enter the PIN on the DIN-rail timer.
