Smart Touch ® Control Screen - Sefa DUPLEX V3 Serie Guia Del Usuario

SMART TOUCH ® CONTROL SCREEN
190°C TEXTILE
25°C
0:10
a� Pressing time
Press here to set the machine's pressing time.
Use the left and right arrow keys to increase and decrease the
setting.
You can also have 4 consecutive pressing times (cf. "settings
(e)") on single-platen presses and up to 4 times for dual-platen
presses.
You can also change this setting by pressing the time display
and entering the required time from the touch pad (4 charac-
ters must be entered).
Once you have entered the required time, press the "confirm"
key in the bottom right corner of the screen.
b� Temperature settings
Press the "temperature" menu (b).
You can select the temperature you require in the same way as
for the pressing time, using the arrow keys on the left and right
of the temperature display. You can also click on the reading
and manually select a temperature. When typing in a tempe-
rature below 100°C, enter a "0" first (e.g. 090°C).
You can also slide the blue cursor left and right with your fin-
ger to lower and raise the temperature respectively, and then
adjust it using the arrows. Select the profile you wish to press
(Textile, Rigid or DTG).
www.sefa.fr
001502
0:10 0:20
0:05 0:15
User guide - SEFA DUPLEX V3 Series
Recipes (d)
Temperature - current & setpoint (b)
Counter & mode (c)
Settings (e)
Pressing time & next pressing times (a)
Stop cycle
190°C TEXTILE
25°C
0:10
190°C TEXTILE
25°C
0:10
TEXTILE
001502
0:10 0:20
0:05 0:15
99 : 99
99 : 99
99 : 99
99 : 99
001502
0:10 0:20
0:05 0:15
190°C
RIGID DTG
