4. Technical data

Voltage supply ........................................18 V d.c.
Idling speed: ............................0-400/0-1500 rpm
Torque settings: ....................................... 21+1+1
Forward and reverse rotation ..........................yes
Chuck clamping width ....................... max. 13 mm
Battery charger output voltage: ............. 20 V d. c.
Battery charger output current: ....................... 3 A
Mains voltage for charger: .. 200-250V~ 50-60 Hz
Battery type: .......................................Lithium-ion
Number of battery cells: .................................... 5
Battery capacitance: ................................. 2.0 Ah
Weight.........................................................1.8 kg
Max. screw diameter: .................................. 6 mm
The maximum screw diameter indicates the ma-
ximum diameter of the screw that can be screwed
into wood. The screw diameter can vary depen-
ding on the type of wood.
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 62841.
L sound pressure level ..................... 84.9 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ......................... 95.9 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 62841.
Drilling in metal
Vibration emission value a
K uncertainty = 1.5 m/s
Impact drilling in concrete
Vibration emission value a
Uncertainty K = 1.5 m/s
The stated vibration emission levels and stated
noise emission values were measured in ac-
cordance with a set of standardized criteria and
can be used to compare one power tool with
another.
Anl_TE_CD_18_48_Li_i_SPK9.indb 20 Anl_TE_CD_18_48_Li_i_SPK9.indb 20
≤ 2.5 m/s
2
h
2
= 8.231 m/s
2
h,ID
2
- 20 -
GB
The stated vibration emission levels and stated
noise emission values can also be used to make
an initial assessment of exposure.
Warning:
The vibration and noise emission levels may vary
from the level specifi ed during actual use, depen-
ding on the way in which the power tool is used,
especially the type of workpiece it is used for.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
Limit the operating time.
All stages of the operating cycle must be conside-
red (for example, times in which the electric tools
are switched off and times in which the tool is
switched on but operates without load).
