4) Concatenated voltage page
• The voltages concatenated between
pK
the phases are displayed
VOLTAGE
V
1
2
3 2
1 3
T
5) Phase current page
➧
pK
A A
CURRENT CURRENT
1
3 2
T
• The phase currents are displayed
• Press "T" to display the system current
5a) Phase current peak value pages
➧
➧
pK pK pK
h h
A
CURRENT CURRENT CURRENT
A
1
3 2
T
• The same procedure as the display of the phase voltage peak values
