Handle, Frame & Wheel Assembly
Ref. Part Number
1 749-04282
2 720-04072
3 749-04281
4 710-04398
5 754-04123
6 756-04163
7 748-04125
8 686-04080
9 712-04065
10 710-0654A
11 786-04303
12 710-0514
13 732-0418
14 738-04139
15 756-04217
16 710-0591
17 710-0520
18 786-04256
19 711-0415
20 642-0005
21 642-0003
22 714-0149B
23 749-04266
18 s 9 — i
ectiOn llustrated
Description
Upper Handle
Star Handle Knob
Lower Handle
Flange Screw: 5⁄16-18:7.5:GR5
V-Belt
Idler Pulley
Shoulder Spacer
Idler Bracket
Flange Lock Nut: 3⁄8-16
TT Screw: 3⁄8-16:1.00
Belt Cover
HH Cap Screw: 3⁄8-16:1.00
Extension Spring
Stud: 33 x 1.5: 3⁄8-16
Flywheel Pulley
HH Cap Screw: 3⁄8-24:1.00
HH Cap Screw: 3⁄8-16:1.55
Tine Shield 61 cm
Clevis Pin
Outer Tine Assembly LH
Inner Tine Assembly LH
Internal Cotter Pin
Rear Wheel Tube
p l
arts ist
Ref. Part Number
24 714-3020 Cotter Pin
25 769-0299 Push Cap
26 734-0973 Wheel 5 x 1.38
27 749-04265 Depth Stake Tube
28 711-04520 Axle Shaft
29 710-1007 TT Screw 3⁄8-16 x 1.50
30 711-0415 Clevis Pin
31 710-0809 TT Screw: 1⁄4-20:1.25
32 737-04202 Pipe Plug: 3⁄8 NPT
33 642-0002 Inner Tine Assembly RH
34 642-0004 Outer Tine Assembly RH
35 618-04276A Case Assembly
36 721-04157 Gasket
37 786-04296 Wheel Bracket
38 712-04063 Flange Lock Nut: 5⁄16-18
39 710-0487 Carriage Bolt
40 731-05385 Clutch Cable Fitting
41 746-04247 Clutch Cable
42 710-0599 TT Screw: 1⁄4-20:.50
43 786-04307 Cable Mount Bracket
44 747-04508 Clutch Bail
45 716-0208 Retaining Ring
46 736-0300 Flat Washer, .406 x .875 x .059
