DRYER INSTALLATION REQUIREMENTS

(Australia and New Zealand – for full details of installation requirements refer to AS/NZS 5601.1)
Location Requirements
Your dryer can be installed in a basement, laundry room, or
recessed area.
This dryer is not intended for installation in a mobile home.
Companion appliance location requirements should also be
considered.
IMPORTANT: Do not install or store the dryer where it will be
exposed to the weather. Proper installation is your responsibility.
You will need:
An earthed electrical outlet located within 1.8 m (6 ft.) of
■
where the power cord is attached to the back of the dryer.
See "Electrical Requirements. "
A level floor with a maximum slope of 25 mm (1") under entire
■
dryer. Installing the dryer on soft floor surfaces, such as carpets
or surfaces with foam backing, is not recommended.
Dryer installation clearances
The location must be large enough to allow the dryer door
■
to be fully opened.
Additional spacing should be considered for ease of installation
■
and servicing. The door opens more than 180°.
Additional clearances might be required for wall, door, and floor
■
moldings.
Additional spacing of 25 mm (1") on all sides of the dryer
■
is recommended to reduce noise transfer.
When installing a dryer:
IMPORTANT: Observe all governing codes and ordinances.
Check code requirements: Some codes limit or do not
■
permit installation of clothes dryers in garages, closets,
or sleeping quarters. Contact your local building inspector.
NOTE: For installation in Australia and New Zealand, install dryer
in accordance with local governance codes.
8
Recessed Area and Closet Installation Instructions
This dryer may be installed in a recessed area or closet. For
recessed area and closet installations, minimum clearances
can be found on the warning label on the rear of the dryer
or in "Dimensions/Clearances. "
The installation spacing is in millimeters and is the minimum
allowable. Additional spacing should be considered for ease
of installation, servicing, and compliance with local codes and
ordinances.
If closet door is installed, the minimum unobstructed air opening in
the top and bottom is required. Louvered doors with equivalent air
openings are acceptable.
The dryer must be exhausted outdoors.
NOTE: For installation in Australia and New Zealand, refer to
AS/NZS 5601.1 for ventilation requirements.
Front
View
Closet
Door
