REPLACEMENT PARTS LIST

For replacement parts, call our customer service department at at 1-877-447-4768, 8:30 a.m. - 4:30 p.m.,
CST, Monday - Friday.
PART DESCRIPTION
A Top Panel
B Top Shelf
C Base
D Left Side Panel
E Right Side Panel
F Left Inner Panel
G Right Inner Panel
H Left Cabinet Door
J Right Cabinet Door
K Adjustable Shelf
L Lower Back Panel
M Upper Back Panel
N Shelf Rail
AA Bolt
BB Flat Washer
CC Lock Washer
DD Dowel
EE Screw
FF Knob Screw
GG Cabinet Door Knob
HH Shelf Support
N
A
20-10-129
PART #
20-12-202
20-12-203
20-12-204
20-12-205
20-12-206
20-12-207
20-12-208
20-12-209
20-12-210
20-12-211
20-12-212
20-12-213
20-12-214
20-12-215
20-12-216
20-12-217
20-12-218
20-12-219
20-12-220
20-12-221
20-12-222
F
B
C
D
AA
DD
GG
G
E
10
BB CC
EE
FF
HH
M
L
J
H
K
