4.3 Versión con bloque de conexión individual
Conexión en línea
Tipo y tamaño
Conexiones P y R
(ISO 228/1)
CMV 1.. -1/4
G 1/4
CMV 1.. -3/8
G 3/8
CMV 2.. -3/8
G 3/8
CMVZ 2.. -3/8
CMV 3.. -1/2
G 1/2
CSV 2.. -1/4
G 1/4
CSVZ 2.. -1/4
CSV 2.. -3/8
G 3/8
CSVZ 2.. -3/8
CSV 3.. -1/2
G 1/2
www.hawe.de | 2015
a
b
c
40
40
25
40
40
25
45
42
32
50
50
35
45
42
32
45
42
32
55
50
35
08-2013-1.3 - D 7710 MV
- CMV, CMVZ, CSV, CSVZ
d
e
f
27
10
10
27
10
10
27
12
12
34
12
12
27
15
15
27
15
15
34
12
12
g
26
26
30,5
33,5
31
31
39
13
