Replacing The Filters - djive Vacumate Ultralight DJ50012 Manual Del Usuario

ATTENTION –

Replacing the Filters

1. Remove the dust bin from the vacuum
(Fig. 1).
2. Pull the metal ring to remove the filter
cartridge from the dust bin (Fig. 2).
3. Turn the metal ring on the filter set
counter-clockwise to remove it from
the cartridge (Fig. 3). The filter set
includes a High-Flow Pleated filter
and a foam filter (Fig. 4).
4. Separate the foam filter from the
pleated filter (Fig. 4). Shake or tap the
foam filter to remove excess dust or
replace with a new filter. Do not wash
the filters.
5. Replace with a new filter set turning it
clockwise until it snaps into the filter
cartridge (Fig. 5).
6. Align the filter cartridge to the dust
bin and slide into place (Fig. 2).
7. Align the markings on the dust bin and
the vacuum (Fig. 6) and slide until it
clicks into place.
ATTENTION –
Always turn off the vacuum before performing any service.
Filters cannot be washed and reused.
Fig. 1
Fig. 2
Fig. 3 Fig. 4
Fig. 5
Fig. 6
15
