15. Technical data

15 1 Technical data

Model code

Serial number

Year of manufacture

Max pressure PS
Project number
Fluid type
Internal volume
Weight
Sound pressure level
Current
Voltage
15 2 Identification code
Series Fan diameter
number
IDE 5
4 = Ø450
5 = Ø560
15 3 Documents supplied with the current model or available at: https://www.modinecoolers.com/documents/
15 3 1 Technical Manual - Instructions for Use
15 3 2 Declaration of Incorporation
15 3 3 Operating Manual - Fans (as long as required)
15 3 4 Circuit diagram (if applicable)
15 3 5 User's manuals for accessories (if any)
38
www.modine.com
Label on the unit
Label on the unit
Label on the unit
Label on the unit
Documents relating to offer / order
Documents relating to offer / order
Label on the unit
Label on the unit
Documents relating to offer / order
Label on the unit and Technical manual Chapt. 9
Label on the unit and Technical manual Chapt. 9
Fan Coil rows Fin spacing
2 A 04
1 A = 6 04 = 4 mm
2 B = 8 07 = 7 mm
3 10 = 10 mm
4
Electric defrost Optional
features
ED 1079
[ED] = optional electric [.xxxx] = optional
defrost features
