AC current (True RMS)
Range Resolution
660 A 0.1 A
1500 A 1 A
•
Crest Factor: ≤3.
•
AC coupled true RMS specified from 5% to 100% of range.
•
Frequency ranges: 50 Hz ~ 1 kHz. Accuracy: ±(0.1% rdg + 5 dgts). The
readings of frequency measurements will show on the sub-display.
•
Minimum Input current Range: >500 dgts.
•
Overload protection: 1500 A AC.
DC current
Range Resolution
660 A 0.1 A
2000 A 1 A
•
Overload protection: 2000 A DC for 60 seconds maximum.
Resistance
Range Resolution
660 Ω
6.6 kΩ
66 kΩ
660 kΩ
6.6 MΩ
66 MΩ
•
Overload protection: 600 V DC or AC RMS.
Continuity test
Range Audible Threshold
Less than 30 Ω
660 Ω
0...660 A
0...660 A
660...1000 A
660...1000 A
1000...1500 A
0...660 A
660...1000 A
1000...2000 A
0.1 Ω ±(1.0% rdg + 5d)
1 Ω ±(1.0% rdg + 5d)
10 Ω ±(1.0% rdg + 5d)
100 Ω ±(1.0% rdg + 5d)
1 kΩ ±(2.0% rdg + 5d)
10 kΩ ±(3.5% rdg + 5d)
CMP-2000 – USER MANUAL
Accuracy
±(2.0% rdg + 10d)
±(3.0% rdg + 10d)
±(2.5% rdg + 10d)
±(3.5% rdg + 10d)
±(5.0% rdg + 10d)
Accuracy
Accuracy
Response Time
Approx. 100 ms
50...60 Hz
61...400 Hz
50...60 Hz
61...400 Hz
50...400 Hz
±(2.0% rdg + 5d)
±(3.0% rdg + 5d)
±(5.0% rdg + 5d)
Open Circuit Voltage
-3.2 V DC
-1.1 V DC
-1.1 V DC
-1.1 V DC
-1.1 V DC
-1.1 V DC
Open Circuit Voltage
-3.2 V DC
