ENGLISH
Cleaning the glass
1. After removing the door and resting it on a soft
surface with the handle downwards, simultaneously
press the two retaining clips and remove the upper
edge of the door by pulling it towards you.
2. Lift and firmly hold the inner glass with both
hands, remove it and place it on a soft surface
before cleaning it. Do the same operation for the
intermediate glass.
3. To reposition both the intermediate and the internal
glass properly, be sure that the "R" can be seen in the
left corner.
First insert the long side of the glass indicated by "R"
into the support seats, then lower it into position.
4. Refit the upper edge: A click will indicate correct
positioning. Make sure the seal is secure before
refitting the door.

What to do if ...

Problem
The oven does not work.
Before calling the Authorized Service Centre:
1. See if you can solve the problem yourself with the help of
the suggestions given in the "What to do if ..." table.
2. Switch the appliance off and back on again it to see if the
fault persists.
If after the above checks the fault still occurs, contact IKEA
Authorized Service Centre.
Always specify:
• a brief description of the fault;
• the type and exact model of the oven;
• the service number (number after the word Service on the
rating plate), located on the right hand edge of the oven
cavity (visible when the oven door is open);
To replace the lamp
1. Disconnect the oven from the power supply.
2. Unscrew the lamp cover (Fig. 5), replace the lamp (see
3. Reconnect the oven to the power supply.
NOTE:
-
-
-
Possible cause
No presence of mains electrical power.
The oven is not connected to the electrical
supply.
The oven selector is turned to "
•
•
Fig. 5
note for lamp type) and screw the lamp cover back
on.
Only use 25W/230 V type G9, T300°C halogen lamps.
The lamp used in the appliance is specifically designed
for electrical appliances and it is not suitable
for household room illumination (Commission
Regulation (EC) No 244/2009).
Lamps are available from IKEA Authorized Service
Centre.
Solution
Verify the presence of mains electrical
power.
Connect the oven to the power supply.
Turn the oven selector and select a cooking
".
function.
your full address;
your telephone number.
If any repairs are required, please contact IKEA
Authorized Service Centre (to guarantee that original
spare parts will be used and repairs carried out
correctly).
21
