Set Function And Trigger Radius - VOSS sonic 360 fusion Instrucciones De Operación

8

SET FUNCTION AND TRIGGER RADIUS

The VOSS.sonic 360 fusion has two separate switches. The function
switch (5) determines the mode to be used (flash, sound/ultrasonic
or a combination of both) and the radius switch (8) determines
the triggering radius (120° to 360°).
Function switch
Switch off the device
Switch on flash
Switch on sound/ultrasound
Switch on sound/ultrasound and flash light
Sound/ultrasound
When the sound/ultrasound is switched on, the device emits
a frequency mix (13.5-23.5 kHz). This frequency mix is used to
scare away dogs, cats, martens, foxes, deer, mice, small animals
and much more.
Flash
Switching on the flash light is intended to scare away birds.
Radius switch
I nfo
Side A is indicated by the symbols on the device.
120° The device only triggers on the side that detects a movement
Side A inactive. Side B and C are active and trigger
240°
simultaneously when movement is detected
Side A, B and C are active and trigger simultaneously when
360°
movement is detected
24
INSTRUCTION MANUAL VOSS.SONIC 360 FUSION
45085 - 11.2022 - V3
