Indicator Lights; Mobile App And Wi-Fi Connection - cecotec CONGA 5290 ULTRA T Manual De Instrucciones

ENGLISH
Recommendations:
− Remove all cables and obstacles from the floor before operating the robot in order to avoid
accidents and damage
− Set stairs as restricted areas.
Robot buttons
Automatic mode
− Press the power button on the robot for it to start cleaning automatically, first a cleaning
cycle in Edge mode and then another cycle in an organised zigzag motion, recognising
which areas it has cleaned and which ones it has not. The robot will automatically plan
the cleaning route as it is cleaning. If during this mode the robot is controlled manually,
the robot will calculate the route again and could go through previously cleaned areas. In
order to ensure efficient cleaning, do not operate it manually during auto mode cleaning.
− Thanks to its Total Surface 2.0 technology, if the battery is low during the cleaning cycle, the
robot will smartly return to the charging base automatically and, once it is fully charged, it
will resume the cleaning process from the same point. During cleaning, the robot will stop
briefly to evaluate the area and calculate the cleaning route (this stop will vary depending
on the house conditions).
Back home mode
− Press the back home button.
− This mode can be activated during any other cleaning cycle and the robot will stop cleaning
and return to the charging base automatically.
− The robot will take the shortest route back to the charging base thanks to its map
memorizing and the smart back home function.
− When a cleaning cycle has been completed or the robot battery is low, thanks to its
TotalSurface 2.0 technology, the robot will also return to the charging base to avoid
running out of battery. Once the robot has recharged, it will resume cleaning from the point
it has stopped.
Fig. 7
Warnings:
Make sure there are no obstacles in the room being cleaned to ensure the robot can get to the
charging base without problems.
Functions
Pause
While the robot is operating, press the power button on the app or on the robot to pause it and
press the same button again to resume cleaning.
36
Standby
− The robot will automatically enter standby mode after 10 minutes of no operation.
− Press the power button on the App or the robot to start it up again.

Indicator lights:

− While the robot is charging, the power light will be oscillating blue until the battery is fully
charged.
− Once the battery is fully charged, the "power" light will turn from oscillating blue to steady
blue.
− When the robot is cleaning, the power light will stay steady blue.
− The home light will turn steady orange when the robot is set on the Back home mode or
when there is a battery fault.
− The "power" light will be oscillating red when there is any type of error, or the tank is not
installed.
− The "power" light will be oscillating blue when the robot is in linking mode.
− The robot has a reset button on the side to restart and/or turn it off, by holding it down
for approximately 3 seconds, the robot will turn off and you will need to press the power
button to use it again. Fig 15.

5. MOBILE APP AND WI-FI CONNECTION

− To access all the robot's function from wherever you are, it is suggested to download the
App. It will allow you to efficiently control your robot and enjoy premium cleaning.
− To set the robot in linking mode, hold down the power and home buttons at once for 5
seconds until the power button oscillates in blue.
App advantages:
− Control your robot in an easy and intuitive way.
− Activate the cleaning process from any point.
− Carry out settings and daily scheduling.
− Choose between its different cleaning modes: Auto, Spiral, Edges, Manual, Restricted area,
Spot, Smart area, Back home. Scrubbing and Complete cleaning.
In addition, in every one of the cleaning modes on the app, you will be able to select the
Twice mode, which performs the selected cleaning process twice, and the Turbo mode on
carpets, which activates the maximum suction power when the robot detects a carpet.
− View how the robot creates an interactive map as it is cleaning.
− Manage rooms smartly through its Room Plan function, which allows you to join, separate
or name rooms. Plus, create and schedule your own cleaning plans by selecting the rooms
you want to clean, the mode and power level.
− Check the cleaned surface and the time taken.
ENGLISH
37
