T&S B-2360-04 Instrucciones De Instalación Y Mantenimiento página 3

Part Number Guide
Bubbler Assembly
11 Body Faucet
21 Shank
31 Washer, Rosette
41 Lock Washer, Brass
51 Locknut, Shank
61 Nut, Coupling
71 Bubbler Volume Control Screw & O-Ring
81 O-Ring, Bubbler Control Volume Screw
91 Spout, Bubbler
10 Flow Straightener
11 Holder, Mouth Guard
12 Screw, Mouth Guard (Qty 2)
13 Rubber Mouth Guard
14 Brass Mouth Guard
15 Anti-Rotation Pins w/ Washer
16 Vandal Resistant Washer, Shank
17 Fast Self-Close Cartridge
18 Lever Handle
19 Vandal Resistant Screw w/ Spanner Bit
20 Assembly, Metering Cartridge w/ Cold Push-Button Cap
21 Cartridge, Push-Button Metering
22 Push-Button Cap, Cold
23 Spanner Bit, #10
24 Blue Button Index, Press-in
3
N/A
N/A
001000-45
000999-45
002954-45
000958-20
012697-45
015319-45
N/A
009594-45
009596-40
009598-45
009595-45
011299-40
012698-45
N/A
015317-40
001638-45NS
VRS-2
238AC
238A
014195-40
014075-45
018506-19NS
