Adjustments
Swivel Adjustment
Refer to the below illustrations to adjust swivel angle.
-20°
Tilt Adjustment (If necessary)
1. Loosen 4 tilting bolts by MAXIMUM 1 turn with
2. Hold the TV with your hands, then adjust TV to your desired angle.
3. Tighten 4 tilting bolts with
0°
+5°
Tilting
Nuts
+20°
Wrench
(J2).
Wrench
Note: When the TV Stand is placed
against the wall, the actual swivel
angle is determined by the screen size.
Wall
(J2).
J2
Tighten
Loosen
Loosen
Tighten
09
Counterclockwise,
Loosen
Clockwise,
Tighten
