Using the Mini Heki Plus
8
Using the Mini Heki Plus
Opening and closing the Mini Heki Plus (fig. c)
8.1
➤ Press the release button (1) and open the roof hood with the bracket at the same
time (2).
Opening the roof light completely
➤ Slide the bracket (2) into the I position.
Opening the roof light to the half-way position
➤ Slide the bracket (2) into the II position.
You can push down the sliders (3) on the left and right to lock it.
Opening the roof light to the ventilation position
➤ Slide the bracket (2) into the III position.
Closing the roof light
➤ Slide the bracket (2) into the IV position.
➤ Guide the bracket (2) with slight pressure to the left and right via the catches (4),
so that the roof hood is locked and the bracket (2) is on the release button (1).
Opening and closing the roller blinds (fig. d)
8.2
A
NOTICE! Risk of damage due to a build-up of heat between the
roller blind and the window.
In strong sunlight, only close the blackout roller blind two thirds of the
way.
I
NOTE
You can adjust the blackout roller blind and the flyscreen separately.
➤ Hold the recessed handle of the roller blind and pull it into the required position.
8
Mini Heki Plus
EN
