BELT CHANGING AND BRUSHROLL CLEANING
4. Rotate cover back. Press cover firmly
until side and rear latches snap into
WARNING
Electrical Shock or Personal Injury
Hazard
Always turn off and unplug vacuum
cleaner before performing maintenance
to the vacuum cleaner. Failure to do
so could result in electrical shock or
personal injury from vacuum cleaner
suddenly starting.
TO CHECK THE BRUSHES
New Brushes
When brushes are worn to the level of the
Cover
Base
BRUSHROLL SERVICING
Worn Brushes
Base
Support
Bar
- 12 -
place.
NOTE:
Make sure there is no gap
between the cover and base.
5. Turn PowerMate
replace the four (4) screws that secure
the cover to the base.
base support bars, replace the brushroll
assembly.
TO REPLACE BRUSHROLL ASSEMBLY
1. Remove the floor brush from the
®
PowerMate
.
2. Remove PowerMate
brushroll assembly. See "To Remove Belt"
in BELT CHANGING AND BRUSHROLL
CLEANING (page 10-11).
3. Install new brushroll assembly.
4. Reinstall belt and PowerMate
"To replace belt" in BELT CHANGING
AND BRUSHROLL CLEANING (page 11-
12).
NOTE:
See REPLACEMENT PARTS for
part number and purchase details (page 5).
®
upside down and
®
cover, belt and
®
cover. See
