General Information
Attention:
We will not assume any responsibility for any damages in the event of:
Use which is improper or which does not conform to that which is intended ;
Repairs that are not carried out at an authorized service centre;
Tampering with the power cable;
Tampering with any component of the machine;
The use of spare parts and accessories which are not original.
In these cases, the guarantee shall be null and void.
Keep these operating instructions in a safe place and attach them to the multi-function cleaner
whenever another person needs to use it.
For additional information or in the event of problems that are not completely or only partially dealt
with in these instructions, contact the specialists responsible.
GENERAL DATA
Power supply 230V - 50Hz
Size (in mm) L. 440 x W. 355 x H 345
Steam pressure 400 kPa (4 bar)
Protective thermostat
Boiler output 1500 W
Motor output 1000 W
Maximum output 2500 Watt
Motor: double turbine
Stainless steel tank
Power cable: 5.2 metres
Hose: 2.3 metres
Required air volume: 45 litres/second
Max. vacuum: 21 KPa
Motor regulation: on handle
Steam volume regulation: from 0 to max.
Low voltage suction and steam controls on the handle
Drain plug for water in boiler
Boiler volume 1,5 litres
Boiler fill tank volume 1,5 litres
SAFETY ELEMENTS
Safety valve for overpressure
Protective thermostat
